Description
The S&F 1206 Self-Aligning Ball Bearing gets designed through precise engineering to support both radial and axial loads in applications which require severe shaft misalignment compensation. The bearing features a diameter of 30mm, outer diameter of 62 mm, and 16 mm width which makes it suitable for all areas with shaft deflection or housing misalignment.
Key Features of 1206 S&F
- Double Row Design: The double row of steel balls allows this bearing to handle more radial loads compared to single-row bearings.
- Self-Aligning Ability: This bearing achieves self-alignment through its spherical outer ring raceway design. The bearing can handle up to 2.5° of angular misalignment while maintaining its original life expectancy.
- Heavy Load Capacity: The bearing supports heavy-duty applications through its dynamic load rating of 15.6 kN and static load rating of 4.65 kN.
- High-Speed Capability: This bearing supports GMRE 8000RPM and GOIL 13,000 RPM when used in high-speed machinery.
- Temperature Range: The bearing functions well while exposed to temperatures that vary from -40 to +120 Celsius degree.
- The Steel Cage: Proper spacing between the balls by the cage reduces friction and wear to extend the bearing’s lifespan.
Applications of 1206 S&F
A variety of industrial applications use the 1206 S&F Self-Aligning Ball Bearing including:
Electric Motors: The bearing aids in the consumption of the motor while cleaning up shaft misalignment in the motor assembly.
Pumps and Compressors: The bearing takes care of the axial, and radial loads to keep a fluid handling system in service.
Agricultural Machinery: The bearing supports loads, while responding to dynamic forces that cause tightening of the equipment.
Conclusion
The 1206 S& F Self-Aligning Ball Bearing provides a consistent answer to heavy load applications, as well, high-speed applications while allowing a measurable degree of shaft misalignment. The bearing promised for exceptional durability for applications that demand consistent performance. If you want to buy the 1206 S & F Self-Aligning Ball Bearing or want further information, you can contact Decent Machinery.
